FEATURES :-
The Machine has automatic fee mechanism which is easy to operate, it also adjust the cutting quantity
& bevelling angel can be adjusted from 0 degree to 45 degree.
Pipe wall thickness from 4 mm to 18 mm the machine can be used easily.
Driven Type
Electric Model:- It is Electrically driven with high performance motor to drive, 220v, 1 phase, Voltage, 50-60 Hz frequency, 1.5 HP -3.0HP Power.
Pneumatic Model:-
A Pneumatic moter adopts to drive. 10-25 bar is Air woking pressure, 1000- 2000L/min is Air consuming flux. Mostly used at dangerous operation places & for inflamable.
Tools:-
| Electric Model | Pneumatic Model | Working Range (inner Diameter/Mn) |
Working Range (Outer Diameter/Mn) |
Max. Wall Thickness (MM) |
Rotating Rate (RPM) |
| BBM-28E | BBM-28P | 16-28 | 19-38 | 18 | 50 |
| BBM-76E | BBM-76P | 28-76 | 32-89 | 18 | 55 |
| BBM-120E | BBM-120P | 40-112 | 48-120 | 18 | 30 |
| BBM-159E | BBM-159P | 65-159 | 72-168 | 18 | 24 |
| BBM-240E | BBM-240P | 80-240 | 90-273 | 18 | 21 |
| BBM-330E | BBM-330P | 150-330 | 160-365 | 18 | 14 |
| BBM-426E | BBM-426P | 245-400 | 260-430 | 18 | 10 |
| BBM-600E | BBM-600P | 300-600 | 320-630 | 18 | 10 |
